| Automatic Chemistry Analyzer | Specifications |
| Analyze Unit |
| Throughput | Constant 180T/h (non-ISE) |
| Theory | Absorption spectrometry, transmission turbidimetry |
| Methodology | End-point,Fixed-time,Kinetic,Ion selective electrode |
| Test according set up, random access |
| Reaction plate | Contain 81 reaction cuvettes |
| Maximum reaction time | 15 minutes |
| Minimum reaction volume | 150 ul |
| Material of cuvettes | Special UV-transparent optical glass |
| Cuvettes use | Automatically cuvettes washing |
| Optical Unit |
| Light Source | Halogen-tungsten lamp |
| Photometer | Reversed optics |
| Wavelength | 340nm-900nm wavelength option |
| Absorption | 0-4 Abs |
| Reagent Unit |
| Reagent plate | 60 reagent positions,support for single and double reagent, reagent
completely open |
| Reagent storage temperature | 2~10℃ |
| Reagent bottle | 15ml, 20ml, 30ml, 50ml or 70ml,dead volume is less than 1.0 ml |
| Reagent volume | 20-500 ul, step by 1.0 ul |
| Reagent/Sample Probe | Automatically checked;Patent technology liquid level
detection;Collision protection probe cleaning:Automatic washing for
both inside and outside. |
| Sample Unit |
| Sample plate | 60 sample positions |
| Sample type | Human (animal) serum,plasma,urine etc. |
| Samples cup | Support one-off micro cups |
| Sample volume | 2-100 ul, step by 0.1 ul |
| Sample/reagent probe | Automatically checked;Patent technology liquid level
detection;Collision protection probe cleaning:Automatic washing for
both inside and outside. |
| Temperature control Unit |
| Heating method | Direct thermal solid thermostat closed |
| Temperature equilibrium time | <3 minutes |
| Reaction temperature | 37±0.1℃ |
| Temperature fluctuation | ±0.1℃ |
| Operation Unit |
| Software | WindowsXP,2000 |
| Database | SQL Server |
| Data Storage | Automatic store & copy; No time and volume limit; Lifetime
preservation |
| Print format | Can be set up, offer several standard format |
| Calibration mode | Linear curve type: Single-point linear, two-point linear and
multi-point linear none linear; Curve type: Logistic-Log
4P,Logistic-Log5p,Spline,index automatically use best calibration
curve and standard |
| Quality control methods: | Real time, within day & between day |
| Quality control diagram | L-J,cumulative,twin plot |
| Status display | Real time monitoring of reagent residual volume.Running status of
reagent tray, samples tray |
| Adjustment | Dynamic and real time display of running status; Intelligent carry
over settings to adjust test sequence; original reaction data
record; Detail profile of alert messages |
| Setting | Operation permission setting, Item setting, cross pollution
setting, cuvette blank setting |
| Others |
| Water consumption: <6L/h | Power Supply: AC 220V±22V 50Hz±1Hz |
| Frequency: Maximum 600VA | Dimension: 782mm×581mm×545mm |
| Net Weight: 60kg | Accessory: Software |
